Butterfly Valves

Our Butterfly valves
SOCVALVES butterfly valves provide reliable and long-lasting flow control in demanding environments. Their compact and robust design makes them ideal for a wide range of industrial applications. Available with various seat types – elastomer, PTFE, metal, or lined – they are suitable for all types of fluids, including highly corrosive or high-temperature media. Thanks to high-quality materials and precision manufacturing, they ensure optimal sealing and consistent performance, both for isolation and flow regulation.
- Valve design according to API 609
- Wide range of specialized alloys available
- Automated options available
Butterfly Valve
Specifications
- Design Standard: API 609
- Size Range: 1/2” à 24” *
- Pressure Range: Class 150 à 1500 *
- End Connections: Flanges RF & RTJ, Butt Weld, Socket Weld, NPT*
- Inspection and Testing: API 598, Leakage Test, API 624 Fugitive Emissions Test
- Flanged End Dimensions: ASME B16.5
- Butt Weld End Dimensions: ASME B16.25
- Socket Weld End Dimensions: ASME B16.11
- NPT End Dimensions: ASME B1.20.1
- Pressure-Temperature Ratings: ASME B16.34
*Consult sales team for additional sizes, pressure classes and end connections.
